#1
03-10-2005, 04:42 PM
|
||||
|
||||
Just doing some research on the location of the rear rear GTO script on a 64 GTO ONLY .
1) your car must have the original quarters still on .Please Do Not particapate if you have changed or know they have been changed 2) measure the distance from the end of the script to the fender extention seam list left side and right side also from the top ridge line to the top of the letters 3)Build date of your car 4)Plant where your car was built The reason is we have found these emblems not to be symetrical on Cars that are known to be orignal.Thaks for your Help. what we find out might be interesting . L) 1 3/4 in to seam 6 in ridge to top of T R) 2 3/8 in to seam 6 in to top of T Build Date 4-23-64 P Mi
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#2
03-10-2005, 04:42 PM
|
||||
|
||||
|
Just doing some research on the location of the rear rear GTO script on a 64 GTO ONLY .
1) your car must have the original quarters still on .Please Do Not particapate if you have changed or know they have been changed 2) measure the distance from the end of the script to the fender extention seam list left side and right side also from the top ridge line to the top of the letters 3)Build date of your car 4)Plant where your car was built The reason is we have found these emblems not to be symetrical on Cars that are known to be orignal.Thaks for your Help. what we find out might be interesting . L) 1 3/4 in to seam 6 in ridge to top of T R) 2 3/8 in to seam 6 in to top of T Build Date 4-23-64 P Mi
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#3
03-10-2005, 07:29 PM
|
||||
|
||||
|
Don:
L) 1 3/4" to seam and 6" top of T to ridge R) 2 3/8" to seam and 6" top of T to ridge I'm not sure of build date. The numbers on the parking brake bracket is 4 6 4 (I think. It's hard to read.) Pretty sure it's a Baltimore car.
__________________
"If you find yourself going through hell, just keep going." 1964 GTO Convertible 1995 Camaro Z28 Convertible 2011 Ford Fusion |
|
#4
03-10-2005, 07:50 PM
|
||||
|
||||
|
Mike, what leter is the 4th didget in your Vin # your car was built the week before mine I bet it's a P if it's a B then there were two different assembly lines that were messed up .
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#5
03-10-2005, 07:54 PM
|
||||
|
||||
|
Fourth digit is "F". Just realized that "F" means Freemont, CA. I guess there were two assembly lines messed up.
__________________
"If you find yourself going through hell, just keep going." 1964 GTO Convertible 1995 Camaro Z28 Convertible 2011 Ford Fusion |
|
#6
03-10-2005, 09:28 PM
|
||||
|
||||
|
F=Fremont,CA
Thats interesting two different assembly lines with incorrect measurements that were the same well lets see how many others respond
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#7
03-11-2005, 04:37 AM
|
|||
|
|||
|
Hi Guys,
My '64 post is totally original & never restored (needs it though!) and fender badges are wrong as well. LH 1 7/8" to seam, 6" to ridge. RH 2 9/16" to seam, 6" to ridge. For the measurements to seam I have taken distance from end of "G" on rhs & end of "O" on lhs as the end of the underline is missing from the lhs (never noticed before!). However, since the rhs badge is complete, the dimension from the end of the underline is 2 5/16" which ties in well with yours. Hopefully you can figure in a correction factor for my lhs? Car built in Pontiac. Build code from data tag 05C = 3rd week May. Sorry I don't have PHS documentation yet, but if you can suggest anywhere else I can find a date code, I'll have a look. Pod. |
|
#8
03-11-2005, 05:57 AM
|
||||
|
||||
|
Pod your badg plasements are the same as GTO Bruins and mine what is the letter in your vin # 4th from the front don't post the whole vin just the letter
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#9
03-11-2005, 10:17 AM
|
|||
|
|||
|
P
|
|
#10
03-12-2005, 05:08 AM
|
||||
|
||||
|
I was hoping for more participation I have 3 other 64s here that all have the same script measurement as the others listed they were all built in the Pontiac Mi plant the latest build date was July 15 64 so it appears that all GTOs built at least from April through July had the same measurements but could we please have more input on original cars Thank You
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#11
03-12-2005, 06:08 AM
|
|||
|
|||
|
Hi Don,
Just found your private message this morning, and have attempted to crawl into the car (its stored for the winter and sandwiched between two others!). In the end I got my wife to do it for me. The park brake code is "554" and the block is "D254". I can decode that as Apr 25th 1964. I presume the brake is May 5th 1964? I'm really pleased that the dates all hold together and seem to confirm that this is an original car? I have headers so couldn't read the manifold dates, and have not taken the valve covers off yet (but I do have 9770716 heads). Can't find the cast date for intake, but manifold is 8436572. Is that correct? I couldn't resist the posting for the production plant. It has to be the shortest post ever on this forum! Of course, that was before I found you private message so please don't think I was being facetious. Since you obviously have looked a quite a few '64 data plates, could you please have a look at my post the other day and give an opinion? Many thanks, Paul. |
|
#12
03-12-2005, 07:08 AM
|
||||
|
||||
|
Paul , It would be worth your while to get the phs . you have another PM
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
|
#13
03-16-2005, 08:49 PM
|
|||
|
|||
|
Don . . .
Mine match Bruins as well. L) 1 3/4 R) 2 3/8 Car is a basket case but best I can tell the quarters are the originals. Wife is sleeping and hid my docs but I will post build date and plant tomorrow. |
|
#14
03-17-2005, 09:05 AM
|
|||
|
|||
|
my NEW 64--taken Nov.64 I'LL take some more soon as I get more coffee,take a shower , get dressed--etc
__________________
GOOD IDEAS ARE OFTEN FOUND ABANDONED IN THE DUST OF PROCRASTINATION |
|
#15
03-17-2005, 09:09 AM
|
|||
|
|||
|
more coffe!! what I ment to say was -more pix of the scipt area-with a ruler stuck to the car for ref.
__________________
GOOD IDEAS ARE OFTEN FOUND ABANDONED IN THE DUST OF PROCRASTINATION |
|
#16
03-17-2005, 04:36 PM
|
|||
|
|||
|
script
__________________
GOOD IDEAS ARE OFTEN FOUND ABANDONED IN THE DUST OF PROCRASTINATION |
|
#17
03-17-2005, 04:48 PM
|
|||
|
|||
|
sorry guys PY wont let me download more than 293K and the first pix of six was 934k.Don I'll send you the pix to your e-mail add.
__________________
GOOD IDEAS ARE OFTEN FOUND ABANDONED IN THE DUST OF PROCRASTINATION |
|
#18
03-17-2005, 06:02 PM
|
|||
|
|||
|
Hi Ken,
Your car looks like I wish mine did! Same colour (Nocturne?) but much better condition! Pod. |
|
#19
03-20-2005, 12:07 PM
|
|||
|
|||
|
Don did you get the pix I sent?
__________________
GOOD IDEAS ARE OFTEN FOUND ABANDONED IN THE DUST OF PROCRASTINATION |
|
#20
03-21-2005, 10:39 AM
|
||||
|
||||
|
I did but please resend then my comp is down on back up from the pics your script matches the other measurements what is the letter in the 4th position in your vin # ?
__________________
"America will never be destroyed from the outside. If we falter and lose our freedoms, it will be because we destroyed ourselves." Abraham Lincoln "A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." — George Washington
|
